Specification
|
1, Kho vajtse Specification |
|
|
Chipset |
ZTE CPU Chip: zx279128s MTK WiFi Chip: MT7976DN / MT7916AN |
|
DDR |
DDR3-2Gb |
|
Flash |
2gb ib |
|
Interface |
4 * GE Ethernet Chaw nres nkoj, 1 * POST Chaw nres nkoj, 1 * USB Chaw nres nkoj |
|
Kav hlau txais xov |
4 * 5dBi cov kav hlau txais xov sab nraud |
|
Khawm |
Hwj chim ON / OFF khawm, WPS khawm, Pib dua khawm, WiFi ON / OFF khawm |
|
Hwj chim |
Tawm tswv yim DC 12V 1.5A |
|
Qhov ntev |
200 hli (L) × 155 hli (W) × 38 hli (H) |
|
Qhov taw qhia LED |
Fais fab, Pon, Los, Internet, Lan1, Lan2 Lan3, Lan4, Tel, 2.4G, 5G, Wps |
|
2, Wireless xov tooj Nta |
|
|
Wireless Standards |
IEEE 802.11ax 5GHz thiab 2.4GHz |
|
Ib puag ncig |
5GHz: Mus txog 2402Mbps |
|
2.4GHz: Mus txog 574Mbps |
|
|
Cov yam ntxwv yooj yim |
SSID tshaj tawm: Pab / Disable; |
|
Beamforming |
|
|
MU-MIMO |
|
|
Kev ruaj ntseg wireless |
WPA-PSK/WPA2-PSK, WPA/WPA2; WPA 3 |
|
Kev Ruaj Ntseg Wireless: Pab kom / Disable; |
|
|
|
|
3, Software nta
Nkag mus interface
Software homepage
NetworkWAN Kev Sib Txuas: PPPoE, DHCP, Static IP, Choj
NetworkWLAN: Ntau SSID, Yooj Yim Mesh
Kev ruaj ntsegURL Lim, Firewall, MAC Lim, IP Lim, Kev Pabcuam Tswj
Daim ntawv thovDDNS, Advanced NAT, UPnP, Voip, IGMP, Txhua hnub, DMS, MLD, DNS, Samba
Kev tswj hwm Uplink hom: PON Uplink, Ethernet Uplink
Kev tu
Qhov zoo & Cov yam ntxwv tseem ceeb
1️⃣ Siab -Speed Dual Band Wi-Fi 6 (802.11ax)
AX3000 wireless kev ua haujlwm
2.4GHz: mus txog 1148Mbps
5GHz: mus txog 2402Mbps
OFDMA thiab MU-MIMO rau kev sib txuas ntawm ntau yam - khoom siv
Tsawg latency rau 4K streaming, gaming, thiab cov khoom siv hauv tsev ntse
2️⃣ XPON Fiber Access nrog Wide Compatibility
Txhawb EPON / GPON (XPON adaptive)
Nws hloov mus rau PON network sib txawv
Tau tshaj ISP infrastructures loj
3️⃣ Tag Nrho Gigabit Ethernet Ports
4 × Gigabit LAN chaw nres nkoj
Zoo tagnrho rau IPTV, NAS, PCs, thiab khoom siv hauv chaw ua haujlwm
Kev ruaj ntseg wired thiab wireless kev ua haujlwm ib txhij
4️⃣ Kev ruaj khov thiab txhim khu kev qha Network Performance
IPv4 / IPv6 dual pawg txhawb nqa
Kev tswj xyuas kev tsav tsheb ntse txo qis kev sib tsoo
Haum rau tsev thiab chaw lag luam me
5️⃣ Kev tswj chaw taws teeb & Kev teeb tsa yooj yim
Web-raws li kev tswj xyuas interface
TR-069 chaw taws teeb tswj kev txhawb nqa
Ua haujlwm zoo rau ISP kev xa tawm thiab kev saib xyuas
6️⃣ Txhim khu kev ruaj ntseg Network
WPA3 / WPA2 encryption
Ntau SSIDs nrog kev cais cov qhua hauv network
Ua-hauv firewall rau kev tiv thaiv ntxiv
7️⃣ Yooj yim Installation & Tu
Desktop thiab phab ntsa -mount installation xaiv
Clear LED ntsuas rau cov xwm txheej ntaus ntawv
Kev xa tawm sai nrog cov nqi kho mob tsawg
FAQ
Q: Cov qauv PON twg X6430 txhawb nqa?
A: Nws txhawb EPON thiab GPON nrog XPON pib- hloov kho.
Q: Cov txiaj ntsig ntawm Wi-Fi 6 yog dab tsi?
A: Wi-Fi 6 muaj kev nrawm dua, qis dua latency, thiab ua haujlwm zoo dua nrog ntau yam khoom siv txuas nrog.
Q: Dab tsi yog Wi-Fi kev pab them nqi ntau?
A: Feem ntau 120-200㎡, nyob ntawm qhov chaw teeb tsa.
Q: Nws puas txhawb IPv6?
A: Yog, IPv4 / IPv6 dual pawg tau txais kev txhawb nqa.
Q: Kuv puas tuaj yeem teeb tsa tus qhua Wi-Fi network?
A: Yog lawm, ntau yam SSIDs thiab cov qhua tuaj koom kev sib cais tau txais kev txhawb nqa.
Q: Puas yog kev tswj hwm chaw taws teeb txaus siab?
A: Yog, TR-069 tswj chaw taws teeb muaj rau kev ua haujlwm ISP.
Cim npe nrov: Tuam Tshoj ax3000 dual band wi fi 6 router, Tuam Tshoj ax3000 dual band wi fi 6 router manufacturers, lwm tus neeg, Hoobkas
